Are you looking for a Laser Cutting Machine that can cut wood, acrylic, plastic, fabric, or many other non-metallic materials? You can use a Goldenlaser system to create intricate designs and highly detailed cutting shapes in all of these materials.
Goldenlaser Laser Cutting Machine can be applied to various industries such as textile & garments, embroidery, industrial soft materials, leather & shoes, bags, advertisement, crafts & gifts, furniture, architectural model, etc.
Our top-of-the-line Laser Cutter Machine includes a feature set that you won’t find on any other system. From small format 700* 400mm , to the mid-size to oversized format 2500* 8000mm , you’ll find higher quality motion control system, auto focus, servo motor driven , integrated vacuum hold-down table, Ethernet/USB Networking Connections, and the most complete feature set included.
Goldenlaser Laser cutting machine Specifications:
| Model |
JG-13090A |
JG-160100 |
JG-180100 |
| Laser tube |
CO2 Hermetic and detached laser tube |
| Moving system |
Step motor system, offline control |
| Cutting(no-load)speed |
0-30000mm/min |
| Engraving(no-load)speed |
0-50000mm/min |
| Laser Power |
100W |
65W/80/100W |
80W/100W |
| Working Size (mm) |
900 x 1300 |
1000 x 1600 |
1000 x 1800 |
| Image form |
AI、BMP、PLT、DXF、DST etc |
| Repeating location |
≤0.05mm |
| Power supply |
AC220V±5% / 50HZ |
| Standard collocation |
Mini air compressor, 550W exhaust，Constant temperature water chiller for laser machine |
Close loop water cooling system,mini air compressor,500w exhaust |
Mini air compressor,500w exhaust |
| Select collocation |
Z axis auto following focusing system |
High pressure blow magnetic valve and controlboard,assistant laser cutting head,conveyer working tale,water chiller |
Assistant laser cutting head,ccd camera auto-recognition equipment |
| Warranty |
12 Months |
| G. W. (Kg) |
360 |
430 |
480 |
